Vehicle-Specific Kit

F-150 (2009 – 2014) 12th Gen. | Enhance Your F-150 Vision – Get Started Today

Discover easy installation guides and solutions for the 2009-2014 F-150 12th Gen with ClearVU Camera solutions. Expert support and resources available.

Everything you need to install ClearVU!

Template #13 Location

Verify your camera housing matches what is shown in the picture*

Drill template placement

How the template lines up on the vehicle. Match the orientation shown and mark the small hole. Remove the camera housing completely before drilling.

SPECIAL NOTE: Trim Plastic Corner on Black plastic backing as pictured, to allow room for sprayer and hose.

See Template #13 on the Drill Template Reference

*Special Note*

Trim plastic as shown to allow space for sprayer, nut and hose.

What You Will Need:

  • Template #13 (Found in your ClearVU Kit)
  • Sharp Razor Blade/Knife
  • Side Cutters
  • Step Drill (Or 5/16” Drill)
  • Torx Bits
  • 10mm Socket
  • Center Punch or Marker
