Vehicle-Specific Kit

Raptor (2017 – 2020) | Enhance Safety Today – Install Now

Discover install solutions for the Raptor (2017 – 2020) with ClearVU Camera Systems. Find tutorials, local installers, and product details.

raptor (2017-2020) installation

Drill template placement

How the template lines up on the vehicle. Match the orientation shown and mark the small hole. Remove the camera housing completely before drilling.

See Template #54 on the Drill Template Reference

Template #54 Location

Verify your camera housing matches what is shown in the picture*

please reference other install photos below

What You Will Need:

  • Template #54 (Found in your ClearVU Kit)
  • Side Cutters
  • Step Drill (Or 5/16” Drill)
  • Torx Bits
  • Socket Set
  • Center Punch or Marker

Need help with your install?

Our team is happy to walk you through it. Call customer service at (716) 398-2246 or email customerservice@clearvucam.com.
